Hot Sale Junction Box for Solar Pv Module Price List
Product details of the junction box for solar pv module
Product Information
The appearance of PNTECH junction box for solar pv module is designed by our top-class R&D team who has spent most of their time in the lab. The stringent norms of quality and cutting-edge technologies ensure the quality of this product. Zhejiang Pntech Technology Co., Ltd. has strong manufacturing strength to meet the global market demand of junction box for solar pv module.
| STYLE | Junction Box | DOCUMEN NO | PNTK-GGS-001 | |||
| SIZE | PN08xy | Signature andseal of | If you do not sign back, this specification is used bydefault. | |||
| Product Images | ||||||
| REFERENCE TUV SUD | ||||||
| MARKING | PNTECH PN08XY 1500V | |||||
| Corresponding current | 20A/25A/30A | |||||
| Rated voltage | 1500V | |||||
| Max working voltage | 100V | |||||
| Ambient temperature | -40~+85℃ | |||||
| Degree of protection | IP65/IP68 ( 1m, 1h) | |||||
| Pollution degree | class A | |||||
| Flame class | UL94-V0 5VA | |||||
| Connecting capacity | 1x4mm2、 12AWG | |||||
| Waterproof Structure | Potting sealant | |||||
| Connection Method | Soldering | |||||
| Insulation Material | PPE+PS | |||||
| Contact Materia | Copper tin plating | |||||
| Volume Of Silicon Gel Upto | 9mm-7.0g | |||||
| Entry cable | 180 ° | |||||
| Diod mode | Rated current | Rated voltage | Rated current | Number | Connection mode | |
| MK4045 | 40A | 45V | 20A | 3 | ||
| MK5045 | 50A | 45V | 25A | 3 | ||
| MK6045 | 60A | 45V | 30A | 3 | ||
Product Details
Diode integrated modules with high current carrying capacity.
Physical isolation between the converging bars to prevent short circuits.
Strong anti-aging and UV resistance of the shell.
Meet the requirements for use in harsh outdoor environmental conditions.
Products Features
