Good Sellingsolar Connector Types Bulk Buy
Company Advantages
· The production of PNTECH solar connector types is empowered with the use of advanced tools and machines.
· We closely monitor and control the quality in every stage to extend the lifespan of the product.
· Zhejiang Pntech Technology Co., Ltd. has a sales network that covers the whole country.
|
STYLE
|
Photovoltaic connector
|
DOCUMEN NO
|
PNTK-P5-008
|
| SIZE |
PV005-T
|
||
|
CONSTRUCTION
FIGURE
|
|
|
|
| STANDARD BASIS |
IEC 62852：2014
|
||
| Rated voltage |
DC 1500V
|
||
| Rated current |
30A
|
||
| Contact material |
Tinned copper
|
||
| Insulation material |
PPO
|
||
| Locking system |
Locking type
|
||
| Degree of protection |
IP65
|
||
| Ambient temperature range |
-40℃~+85℃
|
||
| Upper temperature limit |
100℃
|
||
| Contact resistance of plug connectors |
≤0.5m Ω
|
||
| Withstand voltage test |
8.0KV，1min
|
||
| Flame class |
UL94-V0
|
||
| compatibility |
Compatible with MC4 connectors
|
||
| Salt spray test |
Degree of severity 6
|
||
| Damp heat test |
No damage occurred which could impair normal use
|
||
| Assemblability |
Insertion force ≤50N, withdrawal force ≥50N
|
||
| Connector pulling force |
≥200N
|
||
| Warranty period |
Twenty-five years
|
||
| Packing quantity |
200 sets/box
|
||
Product Details
PPO Material
High heat resistance,flame resistance,high strength,excellent electrical performance,abrasion resistance and environmental protection.
O-RINGS
The connector socket adopts high quality sealing ring to effectively prevent dust and rain from invading.
LOCK CATCH
Snap lock,stable self-locking Easy to open and close.
COMPATIBILITY
The product has strong compatibility and can be compatible with standard connectors in the market.
Products Features
FAQ
Company Features
· Zhejiang Pntech Technology Co., Ltd. is a reliable partner for solar connector types. We have many years of experience in product production and overseas marketing.
· PNTECH spares no effort into the production of solar connector types. By mastering advanced technology, PNTECH is able to produce solar connector types with superior performance.
· For development, PNTECH actively carries out the work of creating a good atmosphere for strenuous efforts and striving for excellence. Get price!
Product Details
With a focus on product's quality, our company pursues perfection in every detail.
No.108, West of Yinxian Avenue. HaishuDistrict, Ningbo, Zhejiang, China, 315012
