For Military Camp Solar Energy System Components 30A by PNTECH
Product details of the solar energy system components
Product Description
Advanced technology and latest machine & equipment are used to ensure PNTECH solar energy system components is manufactured based on the requirements of lean production. The product has stable performance and long service life which our customers are greatly satisfied with. The successful establishment of sales network better guaranteed the development of PNTECH.
| STYLE | Photovoltaic extension cable | DOCUMEN NO | PNTK-D0-001 | |||
| SIZE | DC-00 | |||||
| CONSTRUCTIONFIGURE | ||||||
| STANDARD BASIS UL6703＆UL4703 | ||||||
| Match wire specifications | 14AWG，12AWG，10AWG，8AWG | |||||
| Rated voltage | DC 1000V/1500V | |||||
| Rated current | 30A | |||||
| Connector type | PV004/PV005 | |||||
| Photovoltaic cable type | PV WIRE | |||||
| Photovoltaic cable color | Positive red, negative black | |||||
| Degree of protection | IP65/IP68 | |||||
| Ambient temperature range | -40℃~+85℃ | |||||
| Upper temperature limit | 100℃ | |||||
| Connector contact resistance | ≤0.5m Ω | |||||
| Withstand voltage test | 6.0/8.0KV，1min | |||||
| Flame class | UL94-V0 | |||||
| compatibility | Compatible with MC4 connectors | |||||
| Salt spray test | Degree of severity 6 | |||||
| Damp heat test | No damage occurred which could impair normal use | |||||
| Assemblability | Insertion force ≤50N, withdrawal force ≥50N | |||||
| Connector pulling force | ≥200N | |||||
| Warranty period | Twenty-five years | |||||
| Length | Customized according to customer requirements | |||||
| Packing quantity | According to customer requirements | |||||
Product Details
Quality tinned copper
Tin plating process, oxidation resistance, good conductivity, 99.98% pure copper, low resis-tance.
High quality connector
PC EXL9330C material, tinned copper inner core, flame retardant, high and low temperature resistant, UV resistant.
High quality insulation
The cable is XLPO, flame retardant,high and low temperature resistant,UV resistance and corrosion resistance
Brand printing
PNTECH logo is printed on the line,with clear printing,Buying a brandis more guaranteed.
Products Features
FAQ
Company Feature
• The place where our company is located has a good view. It also owns a convenient transportation for delivery.
• PNTECH has been exploring and developing domestic and foreign markets by taking advantage of e-commerce trend. Based on quality products, we have opened up a vast market.
• PNTECH pays great attention to customers and services in the business. We are dedicated to providing professional and excellent services.
• PNTECH, founded in has a development history of years. We have constantly explored in the industry and have experienced arduous development. Now we are a modern enterprise with a relatively large influence in the industry.
PNTECH's Solar PV Cable,PV Cable,Solar PV Connector,Solar Tool Kits (Only Sales) have excellent quality and affordable price. We have discounts for bulk purchase. If you have any interest, feel free to contact us.
No.108, West of Yinxian Avenue. HaishuDistrict, Ningbo, Zhejiang, China, 315012
