Cheapest Solar Pv Installation Tools Vendor Best Brand

Product details of the solar pv installation tools

Product Description

PNTECH solar pv installation tools comes with an abundance of unique design styles. Multiple safety and quality tests are performed strictly to ensure a superior performance of the product. Zhejiang Pntech Technology Co., Ltd. will provide a set of feasible solution for solar pv installation tools.

STYLE	Photovoltaic connector	DOCUMEN NO	PNTK-P4-009
SIZE	PV004-T6
CONSTRUCTION FIGURE
STANDARD BASIS		IEC 62852：2014
Rated voltage		DC 1000V
Rated current		30A
Contact material		Tinned copper
Insulation material		PC
Locking system		Locking type
Degree of protection		IP65
Ambient temperature range		-40℃~+85℃
Upper temperature limit		100℃
Contact resistance of plug connectors		≤0.5m Ω
Withstand voltage test		6.0KV，1min
Flame class		UL94-V0
compatibility		Compatible with MC4 connectors
Salt spray test		Degree of severity 6
Damp heat test		No damage occurred which could impair normal use
Assemblability		Insertion force ≤50N, withdrawal force ≥50N
Connector pulling force		≥200N
Warranty period		Twenty-five years
Packing quantity		50 sets/box



Product Details

PPO MATERIAL

High heat resistance, flame resistance, high strength, excellent electrical performance,abrasion resistance and environmental protection

WATERPROOF RING O-RINGS

The connector socket adopts high quality sealing ring to effectively prevent dust and rain from invading

LOCK CATCH

Snap lock, stable self-locking Easy to open and close.

COMPATIBILITY

The product has strong compatibility and can be compatible with standard connectors in the market.

Products Features

Good Conductivity

High Heat Resistance

Flame Retardant

Environmental protection

Wear Resisting

Water Resistant
